46.991mm Outer Diameter Planetary Shaft

SKU: 7Y-0225
1 piece
Categories
Sellers

Details

Provides a shaft to mount planetary gears and matching bearings to the carrier. Attributes: • Hardened steel • Outside diameter: 46.99 mm (1.85 in) • Length: 57 mm (2.24 in) • Chamfered ends • Through hole Application: Service component of final and swing drive groups. Consult your owner's manual or contact your local Dealer for more information. Attributes: • Hardened steel• Outside diameter: 46.99 mm (1.85 in)• Length: 57 mm (2.24 in)• Chamfered ends• Through holeApplication:Service component of final and swing drive groups. Consult your owner's manual or contact your local Dealer for more information

Specifications

Part TypeShaft-planetary
Depth (cm)6.00
Width (cm)7.00
Weight (kg)0.71
Volume (cm3)315.00

Compatible Models

EXCAVATOR
311C313D2313D2 LGP315C315D L316E L316F L318B318B N318C318D L318D2318D2 L318E L319C319D319D L319D LN320 L320-A320-A L320-A N320-A S320B320B FM LL320B L320B LL320B LU320B N320B S320B U320C320C FM320C L320D320D FM320D GC320D L320D LN320D LRR320D RR320D2320D2 GC320D2 L320E320E L320E LN320E LRR320E RR320N321B321C321D LCR322 L322 LN322-A322-A L322-A LN322-A N322B322B L322B LN322C322C FM322N323D323D L323D LN323D2 L323E L323E LN323F L324D324D FM324D FM LL324D L324D LN324E324E L324E LN325 L325 LN325-A325-A FM L325-A L325-A LN325B325B L325B LN325C325C FM325C L325D325D FM325D FM LL325D L325D MH326D L326D2326D2 L326F L326F LN328D LCR329D329D L329D LN329D2329D2 L329E329E L329E LN329F L330D2 L330F330F L330F LN335F LCR365B365B II365B L365C365C L365C L MH374D L374F374F LM325D L MHM325D MH
GENERATOR SET
3512B
HEX BASED SPL SOLUTION
330F OEM
LOGGER
322C
MATERIAL HANDLER
M325D L MHM325D MH
MOBILE HYD POWER UNIT
324D LN325C325D325D L329D L329E330F365C L
TRACK FELLER BUNCHER
11901190T1290T1390222902390239124912590511521521B522522B532541551552TK1051TK711TK721TK722TK732TK741TK751TK752
TRACK-TYPE TRACTOR
D1D2D3D3K LGPD3K XLD3K2 LGPD3K2 XLD4K LGPD4K XLD4K2 LGPD4K2 XLD5K LGPD5K XLD5K2 LGPD5K2 XL
UNDERCARRIAGE
OEMS
WHEELED EXCAVATOR
M325C MH
